Illuminating

Long-life, efficient ultra-bright white LED.

6 watt (2 LEDs x 3.0 watt) per unit.

Mirror-bright re ector and prismatic polycarbonate refractor.

Can be used as a NORMALLY-ON or NORMALLY-OFF light as well as on a switched circuit.

CW: Cold-weather unit for use in freezer applications (in temperatures as low as -20°C – 50°C).
PC: Unit features optional photocell technology that auto- matically responds to low exterior lighting levels in "AC" mode.

Long-life, efficient ultra-bright white LED.
6 watt (2 LEDs x 3.0 watt) per unit.
Mirror-bright reflector and prismatic polycarbonate refractor.
Can be used as a NORMALLY-ON or NORMALLY-OFF light as well as on a switched circuit.

Universal 100-300VAC voltage.
Charge rate/power “ON” LED indicator light and push to test switch for mandated code compliance testing.
4.8V long-life, maintenance-free, rechargeable NiCd battery.
Internal solid-state transfer switch automatically connects the internal battery to LED board for minimum 90-minute emergency illumination.
Fully automatic solid-state, two-rate charger initiates battery charging to recharge a discharged battery in 24 hours.
Self-diagnostic test feature continually diagnoses units performance and tests system to ensure reliable operation and to meet electrical and life safety codes.
Field-selectable wiring allows for “AC” operation of the unit to be controlled using a wall-switch or a photocell or any other switching mechanism (please refer to wiring diagram on next page).

Surface mount via easy connect back plate that fits most standard size junction boxes.
Universal K/O pattern on back plate for wall mount.

Five year warranty on all electronics and housing. Battery pro-rated for ve years.
Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.
UL listed for wet locations (0°C – 50°C).
