IMJ-30/IMJ-30G Emergency Exit Light
Description:
This Emergency Exit Light has single or double universal faces with optional red or green letters. Switchable red or green functionally makes it suitable for multiple state and local regulations. Can be mounted on the wall, top or edge and easy installation in minutes. It can be used for up to 90 minutes after being 24 hours fully charged.
TECHNICAL SUMMARY
|
MODEL # |
NAME |
VOLTAGE |
COLOR |
BATTERY |
RECHARGE TIME |
EMERGENCY OPERATION |
LED CHIPS |
WATTAGE |
LUMEN |
CRI |
|
IMJ-30 |
Red Exit Sign |
120/277V |
Red |
build-in 1.2V |
≤24hrs |
≥90mins |
12 |
N/A |
N/A |
80 |
|
IMJ-30G |
Green Exit Sign |
Green |
6 |
|||||||
|
IMJ-30RG |
Red/Green Exit Sign |
Red/Green |
12 |
ELECTRICAL
- Dual 120/277V voltage. Optional multi-tap voltage available.
- Built-in 1.2V 700mAH rechargeable Ni-cd battery for minimum 90 minutes emergency operation
- Maximum 24 hours for full recharge time.
- Test switch and charge indicator.
MOUNTING
- Innovative, easy installation in minutes.
- Universal J-box mounting pattern.
- Single or double face (Universal).
- Optional RED or GREEN letters.
HOUSING
- Injection-molded thermoplastic ABS housing.
- 5VA flame rating.
WARRANTY
- Two years warranty on all electronics and housing. Two years warranty for battery meets UL 924.
- cUL and UL listed for damp location (0°C-40°C).
IMJ-30/IMJ-30G Emergency Exit Light
