Round LED HB 155W IMHB09
Description:
MESTER IMHB09 is a budget-friendly product with a high return on investment. The compact and light-weight housing design provides excellent heat management while also supporting three installation methods - hanging, hook, and surface mount. The hanging method does not require additional adapters for installation, making it easy to operate. MHB09 is a versatile high bay suitable for a variety of areas including warehouses, gyms, covered outdoor areas, garden centers, and mezzanines.
Contact UsConstruction
- Casting thermally conducts LED heat to optimize performance and long life.
- With corrosion-resistant powder coating that provides protection and architectural appearance while adapting well to the environment.
Optics
- Light engines are available in standard 3000K, 4000K, 5000K( 80 CRI) configurations.
- Scalable Lumen Packages from 16,300 to 17,400 Lumens.
- Anti-UV prismatic translucent len is designed to shape the light uniformity and controls the glare light.
Electrical
- Universal 120V or 230V/240VAC input voltage.
- PF >90%, THD <20%.
- Operating Temperature Range: -40°C to 40°C (-40˚F - + 104˚F).
Mounting
- Hook Mount.
- Conduit Pendant Mount.
- U-Bracket Mount.
Warranty
- Three-year warranty.
Certifications
- UL cUL wet location listed.
Note
- Actual performance may differ as a result of end-user environment and application. All values are design or typical values, measured under laboratory conditions at 25°C(±5°C) specifications subject to change without notice.
 |
 |
PERFORMANCE DATA
|
SYSTEM WATTS |
PHOTOMETRY |
3000K (80CRI) |
4000K (80CRI) |
5000K (80CRI) |
|||
|
LUMENS |
LPW |
LUMENS |
LPW |
LUMENS |
LPW |
||
|
155W |
High Bay |
16300lm |
105 lm/W |
17400lm |
112 lm/W |
17400lm |
112 lm/W |
DIMENSION
|
ORDERING GUIDE Example: IMHB09100W12V50KBMLYY |
||||||||
|
|
|
|
|
|
|
|
|
|
|
I |
MHB09 |
155W |
12V 120V |
30K 3000K |
B Black |
ML Medium lens |
Blank With Hook Mount |
Blank |
|
|
High Bay Series |
|
23V 230V/240V |
40K 4000K |
D Dark Bronze |
|
TR Trunnion Mount |
Alphanumeric |
|
|
|
|
|
50K 5000K |
W White |
|
|
|
MOUNTING
